Visual Stimulators

DATAPixx  Lite

Data acquisition and graphics toolbox for vision researchers

The DATAPixx Lite is a multi-function data and video processing USB peripheral for vision research. In addition to a dual-display video processor, the DATAPixx includes peripherals which often need to be synchronized to video during an experiment, including a button box port for precise reaction-time measurement, and triggers for electrophysiology equipment. Because we implemented the video controller and peripheral control on the same circuit board, you can now successfully synchronize all of your subject I/O to video refresh with microsecond precision.

As with all VPixx Technologies Products, the DATAPixx Lite is field upgradable. If you need a new feature in order to follow some exciting new direction in your research, we can develop the functionality in our labs, then email you an update for your DATAPixx Lite.

Features:

• DVI input: Dual link on DVI-I connector
• DVI input frequency: 25 MHz to 330 MHz
• Maximum vertical refresh rate: 200 Hz
• 16-bit video DACs
• Response box interface
• Electrophysiology trigger outputs
• All digital inputs/outputs feature microsecond synchronization to video refresh

More information

Accessories

Product Customization

Download DATAPixx Lite

Datasheet (PDF 385 KB)
