DATAPixx

Data acquisition and graphics toolbox for vision researchers

The DATAPixx is a complete multi-function data and video processing USB peripheral for vision research. In addition to a dual-display video processor, the DATAPixx includes an array of peripherals which often need to be synchronized to video during an experiment, including a stereo audio stimulator, a button box port for precise reaction-time measurement, triggers for electrophysiology equipment, and even a complete analog I/O subsystem. Because we implemented the video controller and peripheral control on the same circuit board, you can now successfully synchronize all of your subject I/O to video refresh with microsecond precision.

As with all VPixx Technologies Products, the DATAPixx is field upgradable. If you need a new feature in order to follow some exciting new direction in your research, we can develop the functionality in our labs, then email you an update for your DATAPixx.

Features:

• DVI input: Dual link on DVI-I connector
• DVI input frequency: 25 MHz to 330 MHz
• Maximum vertical refresh rate: 200 Hz
• 16-bit video DACs
• Response box interface
• Electrophysiology trigger outputs
• Stereo audio stimulator
• 16 ADC channels
• 4 DAC channels
• All analog and digital inputs/outputs feature microsecond synchronization to video refresh

More information

Accessories

Product Customization

Download DATAPixx Datasheet

(PDF 357 KB)
