Siesta 802 EEG

Revolutionary Diagnostics for a Wireless World

Overview

Siesta Ambulatory and Long-Term EEG Recording System

The Siesta is a new wireless amplifier/recorder, which allows the physician to monitor up to 32 inputs from the patient. The Siesta is the first of a new family of wireless products that the Company has developed to provide greater flexibility to the physicians and comfort for the patients.

Siesta also allows remote monitoring and recording of all channels to the computer hard disk via a wireless Ethernet link. This wireless capability gives physicians the option of monitoring a patient's physiological data while the patients are out of bed, helping to ensure

they capture critical clinical events on the recording. The use of wireless products such as the Siesta also provides the opportunity for hospitals or medical clinics to reconfigure hospital beds without incurring substantial capital works expenditure. It allows the hospital to

utilise almost any bed as a virtual sleep clinic or monitoring bed.

Features & Benefits

In pure ambulatory mode, extended multi-day* studies of EEG can be stored to removable compact flash card for easy download to workstation. (Length of recording is affected by number of channels and sample rates and battery type).

Revolutionary Wireless Data Transmission (can be disabled for ambulatory/ home monitoring)

Enables viewing of EEG waveforms prior to patient leaving the laboratory.

Gather data in ways you never dreamed possible:

Siesta's Ethernet radio link provides the clinician with testing options and opportunities never before available. Your patients are free to move about while you continue to monitor the data in virtual real-time. Set up a testing room in just minutes. Use Siesta in PSG/EEG lab or as your best solution for ambulatory testing.

Revolutionary Size

For those who want numbers, just 300 grams (9.6 ounces) with batteries installed. Dimensions 139.7mm x 76.2mm x 38.1mm, 5.5" x 3" x 1.5", (L x W x H).

Revolutionary Flexibility

Siesta provides up to 32 amplified channels for data collection: any physiological signal may be recorded on any channel

• Differential or Referential
• True 16-bit resolution
• Sampling rates to 1024Hz
• Two expansion ports for accessory modules; Oximeter, pressure transducers, event button…available interface for up to 32 additional signals.

Revolutionary Power

Use standard alkaline AA cells, OR

Use rechargeable NiMH battery pack (Recharger built in – recharge Siesta just like you charge your cell phone)… OR

Run Siesta on AC power; just plug in

Revolutionary Data Storage

Ideal for Ambulatory EEG applications, the Siesta records directly to the on-board,

industry standard Compact Flash Card (various capacities available).

 The Siesta can also be used in the Lab for Long-Term EEG monitoring:

• Record all raw data directly to the computer over a wireless network link…error free!!
• Set up your lab quickly and easily: no cables to run
• Spread Spectrum radio network link ensures artifact free data
• transmission
• Patient is untethered…continue to monitor and record while patient is mobile.
• Control Siesta from any computer on the network

Patient with Pouch and

Event button
