Configurations & Solutions for...

Diagnostics Systems for Sleep

Grael System configuration

Grael System







Grael Add-ons

Part Number       Includes:               Description                                                                              Qty

9107-0036-01                               ProFusion 3 Software Suite (PSG online 3 & Profusion PSG 3)

9108-0035-01                               Digital Video 3 software

8300-0139-00                               Video Camera : Vivotek 8161 Box

8300-0140-00                               Video Camera : Vivotek SD8121 PTZ / PAL

7000-0141-00                               Video Camera : Vivotek SD8111 PTZ / NTSC

8022-0020-01                               Ethernet Intercom

7000-0297-00                               Desk Microphone

7500-0078-00                               Ex-Link DC Input data logger

7900-0047-00                               8-Port 10/100 Power over Ethernet PoE Managed Switch

Grael Sensor Kits

Part Number       Includes:               Description                                                                              Qty

7028-0007-01                               Grael PSG Sensor Kit

                           Includes:

                           '00103750                    Triple Thermocouple                                                               1

                           7001-0008-00               Oximeter Probe                                                                     1

                           4423-0009-00               Oximeter retention clip                                                           1

                           7007-0015-01               Sensor Lead Adaptor Sleeve                                                   1

                           7028-0001-01               Grael Body Position Sensor with belt loop                                1

                           7028-0002-01               Grael Trachael Microphone                                                     1

                           7028-0005-01               Grael RIP Bands & Cable                                                        2

7028-0008-01                                Grael PSG Starter Kit

                           Includes:

                           7028-0007-01               Grael PSG Sensor Kit                                                            1

                           '00103469                    ECG Leads 72” 10 pack                                                         1

                           7000-0286-00               Snap Electrodes 110”                                                             1

                           7002-0004-00               Light snap electrodes 72” - 2 pack                                           1

                           7000-0044-00               Gold Cup Electrodes 72” - Box of 10                                        1

                           5400-0011-00               Nasal Cannula 7ft                                                                 10

                           5400-0012-00               Meditrace Electrodes 30 p                                                      2

                           92000031                    TEN2O Paste 4oz Tube                                                           1

                           95000032                    Micropore Tape 1 inch x 10yd 12 pack                                      1

                           95000031                    Transpore Tape 1 inch x 10yd 12 pack                                      1

                           95000025                    Skin Prep Gauze 2x2 square pack                                            1

                           95000009                    Cotton Swab 100 pack                                                             1

                           92000025                    NuPrep Tube 4oz                                                                     1

                           95000013                    Alcohol Prep Pads 200                                                             1

Sample Grael PSG Laboratory Configuration

Part Number       Includes:               Description                                                                              Qty

9028-0001-01                                      Grael System                                                                            1

9107-0036-01                                      ProFusion 3 Software Suite (PSG online 3 & Profusion PSG 3)      1

9108-0035-01                                      Digital Video 3 software                                                              1

8300-0140-00                                      Video Camera : Vivotek SD8121 PTZ / PAL                                  1

8022-0020-01                                      Ethernet Intercom (per room)                                                       1

7000-0297-00                                      Desk Microphone                                                                       1

7028-0008-01                                      Grael PSG Starter Kit for new labs                                               1

Note: For existing sleep labs please use Grael PSG Sensor Kit 7028-0007-01
