Product no longer available

COMPERIO

Clinical EMG System

Comperio is a powerful EMG platform to provide electromyographers the quality you expect and the flexibility you demand at an affordable price.

The unique open architecture design will allow you to build an EMG instrument to meet your special requirements. This instrument is comfortable in any environment, from the electromyographer on the go to the demands of a high-volume hospital laboratory.

Specifications:

• Channels: 2
• Amplifiers:
• Input impedance > 100 M½
• Sensitivity: 2 µV/div to 10 mV/div at 10 divisions
• High freq filter: >25dB at 50/60 Hz
• Noise (µV): 100 dB
• Calibration: Internal
• Electrode Impedance: 1-500 k½
• Temperature Measurement: 20.0 to 40.0 C
• Stimulators: 1
• Stimulus Output: User selectable, Constant Current (0-100 mA), Constant Voltage (0-400V)
• Stimulus Duration: 0.05 to 1 mS (5 µS steps)
• Repetition rate: 0.1-50 Hz or single shot mode
• Stimulus monitor: Control box dial, computer control, monitor readout
• Data Acquisition:
• Resolution: 20 bit
• Sample rate: 32 kHz per channel
• Delay line: software controlled
• Signal trigger: software controlled
• Time base: 0.5mS/div to 1000 mS/div, 20 divisions max.
• System Architecture:
• Central processor: minimum 333 MHz
• RAM memory: minimum 64 MB
• Mass Storage: > 3 GB
• (computer specifications are subject to change)
• Standard Software Applications:
• Nerve Conduction Studies (motor, sensory, F-responses, H-reflexes)
• Needle EMG
• Repetitive Stimulation
• Blink Reflex
• Somatosensory evoked potentials
• Data archive and transfer
• Automated Patient Report Generator
• Optional Software Applications:
• Enhanced DQEMG
• Motor Unit Number Estimation (MUNE)

Configuration:

• Laboratory (Desktop Based) Configuration

or

• Portable (Notebook Based) Configuration

Basic configuration:

• Laptop computer
• Data acquisition unit
• Remote electrical stimulator
• Medical grade power supply
• Display: 1024 x 768

Available upgrades:

• Portable inkjet printer
• Control module for additional ease of use
• Portable, transportable cart with arm and bag
• Display: 1280 x 1024
• Carry Bag

Laboratory configuration:

• Desktop computer
• Data acquisition unit
• Control Module
• Remote electrical stimulator
• Medical grade power supply
• 1280 X 1024 Resolution monitor
• Sturdy cart with arm
• Laser printer
